Android自定义progress
2015-11-09 18:18
369 查看
转载请标明出处:http://blog.csdn.net/u013598111/article/details/49742145,本文出自:【JunTao_sun】
自定义属性
<?xml version="1.0" encoding="utf-8"?>
自定义属性
<?xml version="1.0" encoding="utf-8"?>
<span style="font-size:18px;"><resources> <declare-styleable name="MyView"> <attr name="color" format="color" /> <attr name="color_r" format="color" /> </declare-styleable> </resources> </span>
<span style="font-size:18px;"><LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:progress="http://schemas.android.com/apk/res/com.example.customsProgress" android:layout_width="match_parent" android:layout_height="match_parent" android:orientation="vertical" > <com.example.customsProgress.ProgressView android:id="@+id/ProgressView1" android:layout_width="300dp" android:layout_height="wrap_content" android:padding="40dp" progress:color_r="#ffff0000" progress:color="#ff0000ff" /> <com.example.customsProgress.ProgressView android:id="@+id/ProgressView2" android:layout_width="300dp" android:layout_height="wrap_content" android:padding="40dp" progress:color_r="#ffff0000" progress:color="#ff0000ff" /> <com.example.customsProgress.ProgressView android:id="@+id/ProgressView3" android:layout_width="300dp" android:layout_height="wrap_content" android:padding="40dp" progress:color_r="#ffff0000" progress:color="#ff0000ff" /> <com.example.customsProgress.ProgressView android:id="@+id/ProgressView4" android:layout_width="300dp" android:layout_height="wrap_content" android:padding="40dp" progress:color_r="#ffff0000" progress:color="#ff0000ff" /> </LinearLayout></span>
<span style="font-size:18px;">package com.example.customsProgress; import java.util.Random; import android.content.Context; import android.content.res.TypedArray; import android.graphics.Canvas; import android.graphics.Color; import android.graphics.Paint; import android.graphics.Paint.FontMetrics; import android.graphics.Paint.Style; import android.graphics.Rect; import android.util.AttributeSet; import android.util.Log; import android.util.TypedValue; import android.widget.ProgressBar; public class ProgressView extends ProgressBar { private static final String TAG = "ProgressView"; private int paddingLT = 3; private int paddingRT = 3; private Paint paint; private Rect mbound; private int textWidth; private int textHeight; private int mRealWidth; private int heightMeasureSpe; private Paint rightPaint; private Paint textPaint; public ProgressView(Context context) { this(context, null); // TODO Auto-generated constructor stub } public ProgressView(Context context, AttributeSet attrs) { this(context, attrs, 0); // TODO Auto-generated constructor stub } public ProgressView(Context context, AttributeSet attrs, int defStyle) { super(context, attrs, defStyle); TypedArray a = context .obtainStyledAttributes(attrs, R.styleable.MyView); int progressColor = a.getColor(R.styleable.MyView_color, 0Xff0000ff); int progressColor_r = a .getColor(R.styleable.MyView_color_r, 0Xff0000ff); a.recycle(); int bar = getProgress(); textPaint=new Paint(Paint.ANTI_ALIAS_FLAG); textPaint.setDither(true); textPaint.setColor(0xff00ff00); paint = new Paint(Paint.ANTI_ALIAS_FLAG); rightPaint = new Paint(Paint.ANTI_ALIAS_FLAG); rightPaint.setColor(progressColor_r); paint.setStyle(Style.FILL); paint.setColor(progressColor); mbound = new Rect(); // 测量初始高度 measureText(bar + ""); } @Override protected synchronized void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { super.onMeasure(widthMeasureSpec, heightMeasureSpec); int modeWidth = MeasureSpec.getMode(widthMeasureSpec); int modeHeight = MeasureSpec.getMode(heightMeasureSpec); int width = MeasureSpec.getSize(widthMeasureSpec); int height = MeasureSpec.getSize(heightMeasureSpec); int w = 0; int h = 0; switch (modeWidth) { case MeasureSpec.EXACTLY: w = width; Log.e(TAG, "getMeasuredWidth()" + getMeasuredWidth()); break; case MeasureSpec.AT_MOST: case MeasureSpec.UNSPECIFIED: w = getMeasuredWidth() + getPaddingLeft() + getPaddingRight(); break; } // 控制MeasureSpec.AT_MOST 最大不能超出的范围 w = modeWidth == MeasureSpec.AT_MOST ? Math.min(w, width) : w; switch (modeHeight) { case MeasureSpec.EXACTLY: h = height; break; case MeasureSpec.AT_MOST: case MeasureSpec.UNSPECIFIED: h = (int) ((-paint.ascent() + paint.descent()) + getPaddingTop() + getPaddingBottom()); break; } h = modeHeight == MeasureSpec.AT_MOST ? Math.min(h, height) : h; setMeasuredDimension(w, h); } /** * 测量 progress字体宽高 * * @param text */ private void measureText(String text) { textPaint.getTextBounds(text, 0, text.length(), mbound); textWidth = (int) textPaint.measureText(text); FontMetrics fm = textPaint.getFontMetrics(); textHeight = (int) (fm.descent + fm.ascent); } private int mRight; private int mLeft; private int mRealText; private int mLineHeight; private int mTextHeight; @Override protected synchronized void onDraw(Canvas canvas) { super.onDraw(canvas); // 判断是否到达右末端 boolean isFinishRight = false; canvas.save(); // 获取进度 int progress = getProgress(); // 0~1 速率 *1.0f先 不然会都等于0 float rate = progress * 1.0f / getMax(); // 不断累加 float start = (mRealWidth - textWidth - paddingLT * 2) * rate; String text = progress + "%"; measureText(text); // 右边长度变化 mRight = (int) (start + textWidth + paddingLT * 2 + getPaddingLeft()); // 左边长度变化 mLeft = (int) (start + getPaddingLeft()); // text 加上两个gap的实际宽度 mRealText = textWidth + paddingLT * 2; // 线的实际高度 mLineHeight = -textHeight / 2 + getPaddingTop(); // 字体的高度 mTextHeight = -textHeight + getPaddingTop(); // 判断未画的线 是不是到达 到达就把最变量start值 赋给最大值 if (start + textWidth + paddingLT * 2 > mRealWidth) { start = mRealWidth; // 控制是否继续画 isFinishRight = true; } if (!isFinishRight) { // 画右边线条 drawRight(canvas); } // 标志 是否大于等于实际宽度 float endX = start + textWidth + paddingLT * 2; if (endX >= mRealWidth) { // left 的最点位子,不再继续画 start = mRealWidth - textWidth - paddingLT * 2; drawLeft(canvas, start); } else { // 不满足前面条件 则不断加上去 drawLeft(canvas, start); } // 画进度 要判断endX也行 有点麻烦了 drawText(canvas, text); canvas.restore(); } /** * @param canvas * @param start * 左侧进度 */ private void drawRight(Canvas canvas) { canvas.drawLine(mLeft + mRealText, mLineHeight, mRealWidth + getPaddingLeft(), mLineHeight, rightPaint); } private void drawLeft(Canvas canvas, float start) { canvas.drawLine(getPaddingLeft(), mLineHeight, mLeft, mLineHeight, paint); } private void drawText(Canvas canvas, String text) { canvas.drawText(text, mLeft + paddingLT, mTextHeight, textPaint); } @Override protected void onSizeChanged(int w, int h, int oldw, int oldh) { super.onSizeChanged(w, h, oldw, oldh); // 实际长度 mRealWidth = w - getPaddingLeft() - getPaddingRight(); } /** * dp 2 px * * @param dpVal */ protected int dp2px(int dpVal) { return (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_DIP, dpVal, getResources().getDisplayMetrics()); } /** * sp 2 px * * @param spVal * @return */ protected int sp2px(int spVal) { return (int) TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_SP, spVal, getResources().getDisplayMetrics()); } String[] colors=new String[]{"#fe9d01", "#fe9d01", "#ffbb1c", "#eed205", "#ff8c05", "#ff6600", "#ffa500" }; Random random=new Random(); //改变画笔颜色 public void updataPaintColors(){ this.paint.setARGB(255, random.nextInt(255), random.nextInt(255), random.nextInt(255)); this.textPaint.setARGB(255, random.nextInt(255), random.nextInt(255), random.nextInt(255)); this.rightPaint.setARGB(255, random.nextInt(255), random.nextInt(255), random.nextInt(255)); // int i=random.nextInt(colors.length); // this.paint.setColor(Color.parseColor(colors[i])); // int j= random.nextInt(colors.length); // this.rightPaint.setColor(Color.parseColor(colors[j])); } } </span>
<span style="font-size:18px;">package com.example.customsProgress; import android.R.integer; import android.os.Bundle; import android.os.Handler; import android.os.Looper; import android.os.Message; import android.renderscript.Sampler.Value; import android.app.Activity; import android.view.Menu; import android.view.View; import android.widget.ProgressBar; public class MainActivity extends Activity { private static final int SEND_PROGRESS1 = 1; private static final int SEND_PROGRESS2 = 2; private static final int SEND_PROGRESS3 = 3; private static final int SEND_PROGRESS4 = 4; private ProgressView view1, view2, view3, view4; private Handler handle = new Handler() { public void handleMessage(Message msg) { switch (msg.what) { case SEND_PROGRESS1: int progress1 = view1.getProgress(); view1.updataPaintColors(); view1.setProgress(++progress1); if (progress1 <= 100) { handle.removeMessages(SEND_PROGRESS1); } handle.sendEmptyMessageDelayed(SEND_PROGRESS1, 40); break; case SEND_PROGRESS2: int progress2 = view2.getProgress(); view2.updataPaintColors(); view2.setProgress(++progress2); if (progress2 <= 100) { handle.removeMessages(SEND_PROGRESS2); } handle.sendEmptyMessageDelayed(SEND_PROGRESS2, 30); break; case SEND_PROGRESS3: int progress3 = view3.getProgress(); view3.updataPaintColors(); view3.setProgress(++progress3); if (progress3 <= 100) { handle.removeMessages(SEND_PROGRESS3); } handle.sendEmptyMessageDelayed(SEND_PROGRESS3, 25); break; case SEND_PROGRESS4: int progress4 = view4.getProgress(); view4.updataPaintColors(); view4.setProgress(++progress4); if (progress4 <= 100) { handle.removeMessages(SEND_PROGRESS4); } handle.sendEmptyMessageDelayed(SEND_PROGRESS4, 45); break; } ; } }; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); view1 = (ProgressView) this.findViewById(R.id.ProgressView1); view2 = (ProgressView) this.findViewById(R.id.ProgressView2); view3 = (ProgressView) this.findViewById(R.id.ProgressView3); view4 = (ProgressView) this.findViewById(R.id.ProgressView4); Message ms = handle.obtainMessage(); ms.what = SEND_PROGRESS1; handle.sendMessage(ms); Message ms1 = handle.obtainMessage(); ms1.what = SEND_PROGRESS2; handle.sendMessage(ms1); Message ms2 = handle.obtainMessage(); ms2.what = SEND_PROGRESS3; handle.sendMessage(ms2); Message ms3 = handle.obtainMessage(); ms3.what = SEND_PROGRESS4; handle.sendMessage(ms3); } } </span>好好学习,天天向上。
