Android自定义控件之百分比圆环进度条

标签： android自定义控件圆形进度条
2015-10-15 21:52 5451人阅读 评论(13) 收藏 举报


 分类：

Android自定义View（6）


版权声明：欢迎转载，转载请注明出处http://blog.csdn.net/nugongahou110

目录(?)[+]

首先我们先来看一下效果

分析

我们来看这个进度条应该分为3个小部分

1.中间的圆

2.外边的圆环

3.中间的文字

分开画

这3部分就是需要我们自己画出来的，因此我们需要3根画笔

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置中心园的画笔</span>
mCirclePaint = <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">new</span> Paint();
mCirclePaint.setAntiAlias(<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">true</span>);
mCirclePaint.setColor(mCircleBackground);
mCirclePaint.setStyle(Paint.Style.FILL);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置文字的画笔</span>
mTextPaint = <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">new</span> Paint();
mTextPaint.setColor(mTextColor);
mTextPaint.setAntiAlias(<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">true</span>);
mTextPaint.setStyle(Paint.Style.FILL);
mTextPaint.setStrokeWidth((<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">float</span>) (<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">0.025</span>*mRadius));
mTextPaint.setTextSize(mRadius/<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">2</span>);
mTextPaint.setTextAlign(Align.CENTER);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置外圆环的画笔</span>
mArcPaint = <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">new</span> Paint();
mArcPaint.setAntiAlias(<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">true</span>);
mArcPaint.setColor(mRingColor);
mArcPaint.setStyle(Paint.Style.STROKE);
mArcPaint.setStrokeWidth((<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">float</span>) (<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">0.075</span>*mRadius));</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li></ul>

接下来我们应该在onDraw里面画这3个部分，中间圆和文字都很好画，难点在于外面的圆环应该怎么画呢？

要想画圆环，首先我们现在new出一个矩形

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//画中心园的外接矩形，用来画圆环用</span>
mArcRectF = <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">new</span> RectF(mCircleX-mRadius, mCircleY-mRadius, mCircleX+mRadius, mCircleY+mRadius);</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li></ul>

这个矩形就是圆环的外接矩形，也就是说圆环是这个矩形的内切圆，这样说有点抽象，我们在画布上把这个矩形画出来大家就明白了。

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;">canvas.drawRect(mCircleX-mRadius, mCircleY-mRadius, mCircleX+mRadius, mCircleY+mRadius,mArcPaint);</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li></ul>



看！就是这个矩形，接下来我们在画圆环的时候，这个矩形要作为第一个参数，这样系统就知道如何画这个圆环了，第二个参数为起始的角度，-90读为正北方向。第三个参数为当前的角度，第四个参数false即可，第五个参数就是画笔

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"> <span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//画圆环</span>
canvas.drawArc(mArcRectF, mStartSweepValue ,mCurrentAngle, <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">false</span>, mArcPaint);</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li></ul>

好了，最难的一个部分画完了，剩下的中间圆和文字就简单了

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"> <span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//画中间圆</span>
canvas.drawCircle(mCircleX, mCircleY, mRadius, mCirclePaint);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//画文字      </span>
canvas.drawText(String.valueOf(mCurrentPercent)+<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"%"</span>, mCircleX, mCircleY+mTextSize/<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">4</span>, mTextPaint);</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li></ul>

为了让进度条动起来，我们肯定要修改他的属性，也就是修改他的当前角度，然后再重画，这样圆就动起来了

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"> <span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//判断当前百分比是否小于设置目标的百分比</span>
<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">if</span> (mCurrentPercent<mTargetPercent) {
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//当前百分比+1</span>
mCurrentPercent+=<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">1</span>;
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//当前角度+360</span>
mCurrentAngle+=<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">3.6</span>;
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//每10ms重画一次</span>
postInvalidateDelayed(<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">10</span>);
}</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li></ul>

在values/attr下添加自定义属性

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><resources>
<declare-styleable name=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"PercentageRing"</span>>
<attr name=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"radius"</span> format=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"integer"</span>/>
<attr name=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"circleBackground"</span> format=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"color"</span>/>
<attr name=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"ringColor"</span> format=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"color"</span>/>
<attr name=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"textColor"</span> format = <span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"color"</span>/>

</declare-styleable>
</resources></code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li></ul>

我们自定义了4个属性

1.radius 半径 类型为整形

2.circleBackground 中心园背景颜色 类型为color

3.ringColor 外圆环的颜色 类型为color

4.textColor 文字颜色 类型为color

然后在带有两个参数的构造方法中获取我们自定义属性

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">public</span> <span class="hljs-title" style="box-sizing: border-box;">PercentageRing</span>(Context context, AttributeSet attrs) {
<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">super</span>(context, attrs);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//自定义属性 values/attr</span>
TypedArray typedArray = context.obtainStyledAttributes(attrs,R.styleable.PercentageRing);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//中间圆的背景颜色  默认为浅紫色</span>
mCircleBackground = typedArray.getColor(R.styleable.PercentageRing_circleBackground, <span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">0xffafb4db</span>);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//外圆环的颜色  默认为深紫色</span>
mRingColor = typedArray.getColor(R.styleable.PercentageRing_ringColor, <span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">0xff6950a1</span>);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//中间圆的半径 默认为60</span>
mRadius = typedArray.getInt(R.styleable.PercentageRing_radius, <span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">60</span>);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//字体颜色 默认为白色</span>
mTextColor = typedArray.getColor(R.styleable.PercentageRing_textColor, <span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">0xffffffff</span>);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//最后一定要调用这个 释放掉TypedArray</span>
typedArray.recycle();
}</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li></ul>

我们在xml中可以为进度条设置属性

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"><com.zhangqi.percentagecircle.PercentageRing
android:id=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"@+id/Circle2"</span>
android:layout_width=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"wrap_content"</span>
android:layout_height=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"wrap_content"</span>
app:radius=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"50"</span>
app:circleBackground=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"#ff43CD80"</span>
app:ringColor=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"#ff3cb371"</span>
app:textColor=<span class="hljs-string" style="color: rgb(0, 136, 0); box-sizing: border-box;">"#ffffffff"</span>
/></code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li></ul>

使用起来非常简单

我们只需要在Activity中获取到实例然后设置一个目标百分比就可以了

<code class="language-java hljs  has-numbering" style="display: block; padding: 0px; color: inherit; box-sizing: border-box; font-family: "Source Code Pro", monospace;font-size:undefined; white-space: pre; border-radius: 0px; word-wrap: normal; background: transparent;"> <span class="hljs-annotation" style="color: rgb(155, 133, 157); box-sizing: border-box;">@Override</span>
<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">protected</span> <span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">void</span> <span class="hljs-title" style="box-sizing: border-box;">onCreate</span>(Bundle savedInstanceState) {
<span class="hljs-keyword" style="color: rgb(0, 0, 136); box-sizing: border-box;">super</span>.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
mPercentageRing1 = (PercentageRing) findViewById(R.id.Circle);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置目标百分比为30</span>
mPercentageRing1.setTargetPercent(<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">30</span>);

mPercentageRing2 = (PercentageRing) findViewById(R.id.Circle2);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置目标百分比为50</span>
mPercentageRing2.setTargetPercent(<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">50</span>);

mPercentageRing3 = (PercentageRing) findViewById(R.id.Circle3);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置目标百分比为70</span>
mPercentageRing3.setTargetPercent(<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">70</span>);

mPercentageRing4 = (PercentageRing) findViewById(R.id.Circle4);
<span class="hljs-comment" style="color: rgb(136, 0, 0); box-sizing: border-box;">//设置目标百分比为100</span>
mPercentageRing4.setTargetPercent(<span class="hljs-number" style="color: rgb(0, 102, 102); box-sizing: border-box;">100</span>);
}

}</code><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li></ul><ul class="pre-numbering" style="box-sizing: border-box; position: absolute; width: 50px; top: 0px; left: 0px; margin: 0px; padding: 6px 0px 40px; border-right: 1px solid rgb(221, 221, 221); list-style: none; text-align: right; background-color: rgb(238, 238, 238);"><li style="box-sizing: border-box; padding: 0px 5px;">1</li><li style="box-sizing: border-box; padding: 0px 5px;">2</li><li style="box-sizing: border-box; padding: 0px 5px;">3</li><li style="box-sizing: border-box; padding: 0px 5px;">4</li><li style="box-sizing: border-box; padding: 0px 5px;">5</li><li style="box-sizing: border-box; padding: 0px 5px;">6</li><li style="box-sizing: border-box; padding: 0px 5px;">7</li><li style="box-sizing: border-box; padding: 0px 5px;">8</li><li style="box-sizing: border-box; padding: 0px 5px;">9</li><li style="box-sizing: border-box; padding: 0px 5px;">10</li><li style="box-sizing: border-box; padding: 0px 5px;">11</li><li style="box-sizing: border-box; padding: 0px 5px;">12</li><li style="box-sizing: border-box; padding: 0px 5px;">13</li><li style="box-sizing: border-box; padding: 0px 5px;">14</li><li style="box-sizing: border-box; padding: 0px 5px;">15</li><li style="box-sizing: border-box; padding: 0px 5px;">16</li><li style="box-sizing: border-box; padding: 0px 5px;">17</li><li style="box-sizing: border-box; padding: 0px 5px;">18</li><li style="box-sizing: border-box; padding: 0px 5px;">19</li><li style="box-sizing: border-box; padding: 0px 5px;">20</li><li style="box-sizing: border-box; padding: 0px 5px;">21</li><li style="box-sizing: border-box; padding: 0px 5px;">22</li></ul>

完整代码

完整代码的注释很清楚，我就不贴出来了，大家可以上我的GitHub上面下载完整代码
